| Technical Data | |||
|---|---|---|---|
|
Technical specifications can be changed without previous notice. |
|||
| Power, mixing pump |
5.5 PS (4.0 kW)
|
5.5 HP (4.0 kW)
|
|
| Fuel |
elektrisch
|
electrical
|
|
| Pump discharge rate |
850 l/min
|
200 gpm
|
|
| Flow rate to boring unit |
850 l/min
|
200 gpm
|
|
| Distance to boring unit |
60 m
|
200 ft
|
|
| Fluid pressure |
25 m (2.5 bar)
|
360 psi
|
|
| Typical mixing time per 1'000 ltr of water |
5 min
|
5 min
|
|
| Mixing hopper capacity |
25 kg
|
55 lbs
|
|
| Drilling fluid tank capacity |
2000 / 3000 l
|
530 / 750 gal
|
|
| Dimensions with one tank L x W x H |
2300 x 1400 x 1850 mm
|
90 x 55 x 70 in
|
|
| Dimensions with two tanks L x W x H |
2300 x 2200 x 1850 mm
|
90 x 85 x 70 in
|
|
| Weight with one tank (empty) |
520 kg
|
1145
|
|
| Weight with two tanks (empty) |
805 kg
|
1775
|
|
